Self Loading Truck Underground 6 Ton To 20 Ton Diesel Power

1
MOQ
Self Loading Truck Underground 6 Ton To 20 Ton Diesel Power
Features Gallery Product Description Request A Quote
Features
Specifications
Engine Model: YUCHAI Engine With Turbocharge
Engine Power: 290HP
Transmission Model: FASITE 9JS118
Drive Mode: 4x2
Dimension Of Bottom Spring Plate: Length 91mm, Width 17mm
Cabin: Canopy
Type Of Bucket: U Type
Fuel Type: Diesel
Condition: New
High Light:

self loading diesel power truck underground

,

20 ton truck underground

,

diesel power underground truck

Basic Infomation
Place of Origin: China
Brand Name: Beijun
Certification: CE,ISO
Model Number: UQ-20
Payment & Shipping Terms
Packaging Details: Customized packaging
Delivery Time: 7-10 days
Payment Terms: L/C, T/T
Supply Ability: 1000 Set/Sets per Month
Product Description

Product parameters of 20 Tons Diesel Underground Mine Dump Truck



UQ-20 highlights strong power, low energy consumption, easy maintenance, and high driving comfort. The combination of strong power and outstanding vehicle performance provides higher productivity with less cost. The mining truck has a compact structure and can pass through the cab (front part), suspension, frame, cargo compartment, lift Special design such as mechanism, compact structure.



Dump truck refers to a vehicle that unloads goods by hydraulic or mechanical lifting. The carriage of the dump truck tilts backwards, and the movement of the piston rod is controlled by the control system. Backward tilting is more common. Pushing the piston rod to tip the carriage is a common transportation tool. Multifunction transmission integrated with a variable torque converter having locking function, integrated hydraulic retarder unit, advanced performance and reliability. Gearbox shaft differential lock drive with higher ability. The middle and rear drive shaft linked, real- time driving; wheel differential lock to effectively deal with the bad road. According to the characteristics of underground humid air, insufficient light, and slippery road surface, the lamps and electrical components of the vehicle have been improved, and the waterproof and moisture-proof performance has been enhanced.



Our company will build a number of regional procurement centers in China, and establish a stable domestic supply channel. We will also establish overseas warehouses and parts warehouses around the world,and after-sales outlets, at the same time implement the "one car one file" quality and information trade ability system to ensure the vehicle experience of every overseas buyer.



Model UQ-20
Engine Model YUCHAI Engine with Turbocharge
Engine Power 290HP
Total Dimension 6200*2400*2450mm
Transmission Model FASITE 9JS118
Transmission Gear 8 Forward Gear, 1Back Gear,Rear High Speed Controller
Drive Mode 4x2
Front Axle Model Styer Axle
Rear Axle Model Styer Axle
Tire Model 10.00-20 Radial steel tire,
Rear Double Tyre One Side,
No.of Bottom Spring Plate Front 11 PCS, Rear 12 PCS
Dimension of Bottom Spring Plate Length 90mm, Width 16mm
Size of the Bucket:Length×width×height 4500mm*2400mm*1000mm
Type of Bucket U- Type
Thickness of Bucket Steel Plate bottom 10mm side 8mm
Unloading Type Hydraulic Double Top Dump
Steering Type Hydraulic power steering
Braking Type Air Brake
Cabin Canopy
Driving Position Left Hand Drive
Cooling sytem Standard Water Cooling System
Loading Capacity 20 Tons
