70 Tons Sand And Stone Transport Mine Dump Truck

1
MOQ
70 Tons Sand And Stone Transport Mine Dump Truck
Features Gallery Product Description Request A Quote
Features
Specifications
Dimension(Lx W XH)(unloaded)(mm): 9045*3200*3770
Cargo Body Size (LxWxH) (mm): 5500x3100x1800 ,Front Lifting, Bottom 12 Mm, Side 10 Mm
Approaching Angle/Departure Angle(°): 32/40
Overhang(front/rear) (mm): 1500/1800
Wheel Base (mm): 3600+1500
Max Speed(km/h): 60
Curb Weight(kg): 29300
Min. Ground Clearance(mm): 340
Max. Gradeability(%): 42
Basic Infomation
Place of Origin: China
Brand Name: Beijun
Certification: CE,ISO
Model Number: 70 ton
Payment & Shipping Terms
Packaging Details: Customized packaging
Delivery Time: 7 days
Payment Terms: L/C, T/T
Supply Ability: 1000 Set/Sets per Month
Product Description

Product Features of 70 Tons Underground Mining Used Dump Truck



Specialization: Accurately meet your requirement Experienced engineers serving for you
We will reply you for your inguiry in 24 hours
Great variety and wide range:your"One-shop purchasing service

SPECIFICATION of 70 Tons Mining dump truck
Dimension(Lx W xH)(unloaded)(mm) 9045*3200*3770
Cargo body size (LxWxH) (mm) 5500x3100x1800 ,Front lifting, Bottom 12 mm, Side 10 mm
Approaching angle/Departure angle(°) 32/40
Overhang(front/rear) (mm) 1500/1800
Wheel base (mm) 3600+1500
Max speed(km/h) 60
Curb weight(kg) 29300
Min. ground Clearance(mm) 340
Max. gradeability(%) 42
Min. turning Radius(e) 22
Engine(Steyr technology, made in China) Model WD615.47,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection
Fuel type Diesel
Power, max(kw/rpm) 371HP
Emission EUROII
Fuel tanker capacity(L) 500L aluminum oil tank
Transmission Model HW21712, 12 speeds forward and 2 reverse
Brake system Service brake Dual circuit compressed air brake
Parking brake spring energy, compressed air operating on rear wheels
Steering system Model ZF8118
Front axle HF12,Steering with double T-cross section beam
Rear axle AC26, (cast steel 2×26ton hub-reduction axle)
Tire 14.00R25 (Radial Tyre)
Cab HW7D cab, (with air-condition), Unilateral cab
Electrical system Battery 2X12V/165Ah
Alternator 28V-1500kw
Starter 7.5Kw/24V

70 Tons Sand And Stone Transport Mine Dump Truck 070 Tons Sand And Stone Transport Mine Dump Truck 170 Tons Sand And Stone Transport Mine Dump Truck 2
