BJUK-30 Articulated Underground Mining Truck With A Carrying Capacity Of 30 Tons
The BJUK-30 truck is an articulated underground mining truck with a carrying capacity of 30 tons. This model has innovative features, which can easily cope with harsh working conditions, provide strong power, strength and reliability to help you maximize productivity .
Heavy-duty front and rear racks are specially designed to deal with harsh underground environments, and the excellent quality, reliability and durability meet user requirements, making transportation simpler, more efficient, and more efficient.
The central hinged swing reduces the large center of gravity offset of the whole vehicle, and ensures that the front and rear frames can swing freely, ensuring that the tires form a good contact with the ground under severe working conditions. The fully sealed slewing bearing device can effectively deal with the harsh working environment, prolong the service life and reduce the operating cost.
| The equipment is designed according to the standard | |
| JB/T8436 Tire-type mine truck for underground mining | |
| JB/T5501 Test method for underground scrapers | |
| GB21500 Safety requirements for trackless tire-type mine trucks for underground mining | |
| BJ12.1-2011 Standard for underground mine trucks | |
|
Motion transfer system
power system |
|
| diesel engine | Mercedes Benz OM460LA |
| rated power | 315 kW @ 1800rpm |
| maximum torque | 2000Nm @ 1300rpm |
| Number of cylinders | Inline 6-cylinder |
| Exhaust volume | 12.8 L |
| cooling system | water-cooled engine |
| Fuel System | Silicone oil clutch fan |
| air intake system | Integrated hand pump, fuel filter |
| Control System | turbo |
| start the system | Dry air filtration, pre-filtration + two-stage filtration |
| Emission Standards | Electronic fuel injection system |
| exhaust system | 24V starter motor |
| Average fuel consumption, | 38.0 L/h |
| At 50% load | 430 L |
