Product Features:
Beijun electric mining truck's features make it a highly attractive option for companies operating in industrial settings. Its zero-emission operation is particularly useful in reducing carbon footprint, which many companies are prioritizing as sustainability becomes a more pressing concern. The truck's high safety features, energy recovery system, and dynamic performance also make it ideal for navigating challenging terrains and environments that are typical of the industries it serves.
The truck's low operating and maintenance costs are additional benefits that can help companies save money in the long run. By requiring less maintenance and having fewer moving parts than traditional diesel-powered trucks, the Beijun electric mining truck can help reduce downtime and keep operations running smoothly.
Overall, the Beijun electric mining truck's combination of environmental friendliness, safety, and efficiency make it a compelling option for companies looking to improve their material transportation operations. As the need for sustainable practices in the industrial sector continues to grow, it will be interesting to see how electric vehicles like the Beijun electric mining truck continue to evolve and be adopted by companies in a range of industries.
| Specification of Beijun Electric Mining Truck | ||
| Product configuration description | 287 KWh single motor | 350 KWh double motor |
| Product number | BJ90A | BJ90B |
| Best working Application | Heavy downhill | Heavy downhill |
| Dynamic parameters | ||
| Power system model | single motor | Dual motor |
| Rated power and speed kW/rpm | 360/1492 (peak) 250/1492 (rated) |
2 x 300/4670 (peak) 2×225/4670 (rated) |
| Maximum torque and speed Nm/rpm | 2800/1492 (peak) 1600/1492 (rated) |
2 x 700/4670 (peak) 2×460/4670 (rated) |
| Battery capacity kwh/displacement L | 287 | 350 |
| Gearbox | ||
| Transmission model | TS-0725 | 7D20K |
| Drive axle | ||
| Front axle rated load (Kg) | 20000*1 | 20000*1 |
| Rated load of rear axle (Kg) | 35000*2 | 35000*2 |
| Tire specifications | Radial tire 14.00R25 | Radial tire 14.00R25 |
| Cargo box parameters | ||
| Body size (mm) | 5800*3200*1800 | 5900*3200*1800 |
| Standard bucket capacity flat pack/stack (m³) | 30/36 | 30/36 |
| Weight parameter | ||
| Total mass (kg) | 90000 | 90000 |
| Curb weight (kg) | 35000 | 36000 |
| Loading mass (kg) | 55000 | 54000 |
| Bridge load front/middle/rear (t) | 20/35/35 | 20/35/35 |
| Operational performance | ||
| Maximum speed km/h | ≤40 | ≤45 |
| Maximum grade% | ≥30 | ≥35 |
| Turning radius (front) mm | ≤11000 | ≤11000 |
