Product Features of 35 Tons Underground Mining 6*4 Dump Truck
Compact and Maneuverable Design: The Beijun underground tunnel dump truck is designed to be compact and highly maneuverable, with a small turning radius and a specially designed cab, suspension frame, and cargo compartment. This allows it to operate effectively in narrow spaces, such as underground roadways and ramps, where maneuverability is essential.
Improved Safety Features: The dump truck is equipped with improved lamps and electrical components that are waterproof and moisture-proof, as well as dedicated anti-slippery tires. These features enhance its obstacle-crossing capability and ensure high safety in the underground environment, which can be hazardous due to poor lighting, slippery surfaces, and other factors.
Powerful Performance: The Beijun underground tunnel dump truck has a powerful engine with large torque, excellent grade, and starting performance. This enables it to transport heavy loads effectively in the underground environment, where the terrain can be challenging.
High Bearing Capacity and Durability: The dump truck is designed and configured according to mining vehicle design concepts, with a bearing capacity that is 1.5 times that of ordinary road vehicles. Additionally, it is built with sturdy materials and components, ensuring its durability in harsh underground conditions.
Overall, the Beijun underground tunnel dump truck offers a range of advantages over other vehicles in its class, including its compact and maneuverable design, improved safety features, powerful performance, and high bearing capacity and durability. These benefits make it a reliable and efficient choice for businesses and organizations that require a robust and practical vehicle for underground mining or construction operations.
Product parameters of 35 Tons Underground Mining 6*4 Dump Truck
Model | UQ-35Q |
Engine Model | YC6MK375-T300 |
Engine Power | 276kW |
Total Dimension | 7748x2500x2700 |
Transmission Model | 10JS220 |
Transmission Gear | 10 Forward Gear, 2Back Gear,Rear High Speed Controller |
Drive Mode | 6x4 |
Front Axle Model | Styer Axle |
Rear Axle Model | Styer Axle |
Tire Model | 12.00R20 |
No.of Bottom Spring Plate | Front 11 PCS, Rear 12 PCS |
Dimension of Bottom Spring Plate | Front 90*16 Rear 90*24 |
Size of the Bucket:Length×width×height | 5400x2500x1350mm |
Type of Bucket | Right Angle Type |
Thickness of Bucket Steel Plate | bottom 10mm side 8mm |
Unloading Type | Hydraulic Double Top Dump |
Steering Type | Hydraulic power steering |
Braking Type | Air Brake |
Cabin | Closed Cabin |
Driving Position | Left Hand Drive |
Cooling sytem | Standard Water Cooling System |
Loading Capacity | 35 Tons |
