Product parameters of 10 Tons Mine Dump Trucks
The trusted workhorse of miners and tunneling professionals, the UQ-10 Low Profile Dump Truck is ideal for medium size rock excavation operations that require high haulage productivity. The UQ-10 maintains the simple yet very robust design tenets of what a mining equipment should be. Underground dump trucks aim to increase the production of underground mining applications, reduce transportation costs per ton, and carry payloads of 3 to 55 tons and above. Underground dump trucks can be used for underground mining and tunnel construction in hard and soft rocks.Underground mine trucks have improved steadily with the times. Technology affords the operators conveniences that were not available before and sophisticated electronics allow maintenance technicians to effectively diagnose problems. Today’s machines are designed with safety and service in mind. Even though they have made great strides, there is still room for improvement. Articulated underground dump trucks: Articulated dump trucks (articulated between the cab and the dump truck box) are widely produced in civil and mining industries. Articulated dump trucks are large, heavy dump trucks used for cross-country bulk cargo transport across rough terrain.
1.Major components from industry respected suppliers
2.Simple yet very robust design
3.Very competitive pricing compared to its counterparts coming from well-known brands
4.Competitive delivery
The mining equipments including the above referred UQ-10 dump trucks are exported to many foreign countries like Russia, Mongolia, Kazakhstan, Vietnam, Myanmar, Indonesia, Morocco, Zambia, Congo, South Africa, Peru, and Nicaragua, Bolivia, etc. If you are interested in this mining tipper lorry, please do not hesitate to contact us.
Model | UQ-10 |
Engine Model | YUNEI 4102 with Turbocharge |
Engine Power | 70KW/95HP |
Total Dimension | 4800*1800*1600mm |
Transmission Model | Wanliyang 545 |
Transmission Gear | 5 Forward Gear, 1Back Gear,Rear High Speed Controller |
Drive Mode | 4x2 |
Front Axle Model | 1098 |
Rear Axle Model | 1098 |
Tire Model | 750-16 Line Tire, Rear Double Tyre One Side, |
No.of Bottom Spring Plate | Front 10 PCS, Rear 10 PCS, Spare 6PCS |
Dimension of Bottom Spring Plate | Length 70mm, Width 10mm |
Size of the Bucket:Length×width×height | 3200mm*1800mm*600mm |
Type of Bucket | U type Bucket |
Thickness of Bucket Steel Plate | bottom 8mm side 6mm |
Unloading Type | Hydraulic Double Top Dump |
Steering Type | Hydraulic power steering |
Braking Type | Air Brake |
Cabin | Canopy |
Driving Position | Left Hand Drive |
Cooling sytem | Standard Water Cooling System |
Loading Capacity | 10 Tons |
