ISO 25Tons Four Wheel Drive Articulated Truck For Mining Transportation

1
MOQ
ISO 25Tons Four Wheel Drive Articulated Truck For Mining Transportation
Features Gallery Product Description Request A Quote
Features
Specifications
Engine Model: Yuchai YC6L340-33
Engine Power: 243KW
Transmission Model: FASITE RT11509C
Drive Mode: 6x4
Dimension Of Bottom Spring Plate: "Front 90*16 Rear 91*25
Cabin: Closed Cabin With A/C
Type Of Bucket: Right Angle Type
Loading Capacity: 25 Tons
Cooling Sytem: Standard Water Cooling System
High Light:

25Tons Four Wheel Drive Dump Truck

,

ISO Four Wheel Drive Dump Truck

,

ISO 4 wheel drive dump truck

Basic Infomation
Place of Origin: China
Brand Name: Beijun
Certification: CE,ISO
Model Number: UQ-25
Payment & Shipping Terms
Packaging Details: Customized packaging
Delivery Time: 14 days
Payment Terms: L/C, T/T
Supply Ability: 1000 Set/Sets per Month
Product Description

Product Features of 25 Ton Mining Underground Dump Truck Tipper Truck



1. Dump truck suitable for earthwork, gravel, bulk materials,etc.;
2. Dump truck loading compartment can automatically dump a certain angle of unloading, saving unloading time and labor,
short transportation cycle and high production efficiency;
3. Dump truck low transportation costs;
4. Customized design to meet different customer needs.



Product parameters of  25 Ton Mining Underground 25 Ton Dump Truck Tipper Truck


Model UQ-25
Engine Model Yuchai YC6L340-33
Engine Power 243KW
Total Dimension 7900x2420x2720mm
Transmission Model FASITE RT11509C
Transmission Gear 10 Forward Gear, 2Back Gear,Rear High Speed Controller
Drive Mode 6x4
Front Axle Model Styer Axle
Rear Axle Model Styer Axle
Tire Model 1100R20 Radial steel tire,
Rear Double Tyre One Side,
No.of Bottom Spring Plate Front 11 PCS, Rear 12 PCS
Dimension of Bottom Spring Plate Front 90*16
Rear 90*24
Size of the Bucket:Length×width×height 5000x2300x1200mm
Type of Bucket Right Angle Type
Thickness of Bucket Steel Plate bottom 10mm side 8mm
Unloading Type Hydraulic Double Top Dump
Steering Type Hydraulic power steering
Braking Type Air Brake
Cabin Closed Cabin with A/C
Driving Position Left Hand Drive
Cooling sytem Standard Water Cooling System
Loading Capacity 25 Tons
