U Type Bucket 73HP Mini Articulated Truck 5 Ton Red Tipper Truck High Safety

1
MOQ
U Type Bucket 73HP Mini Articulated Truck  5 Ton Red Tipper Truck  High Safety
Features Gallery Product Description Request A Quote
Features
Specifications
Engine Model: FAW - 4DW92-73
Engine Power: 54KW/73HP
Transmission Model: WANLIYANG 530
Drive Mode: 4x2
Dimension Of Bottom Spring Plate: Length 70mm, Width 100mm
Loading Capacity: 5 Tons
Type Of Bucket: U Type Bucket
Thickness Of Bucket Steel Plate: Bottom 8mm Side 6mm
High Light:

73HP Mini Dump Truck

,

73HP Red Tipper Truck

,

U type Bucket Mini Dump Truck

Basic Infomation
Place of Origin: China
Brand Name: Beijun
Certification: CE,ISO
Model Number: UQ-5
Payment & Shipping Terms
Packaging Details: Customized packaging
Delivery Time: 7 days
Payment Terms: L/C, T/T
Supply Ability: 1000 Set/Sets per Month
Product Description

Product parameters of Mini Underground Mining Dump Truck with Loading Capacity 1ton to 5 tons



Small dump trucks are designed with maneuverability in mind, making them an excellent choice for navigating tight spaces and narrow roads that larger trucks cannot access. This makes them a popular choice for construction and landscaping projects with limited space.



Small dump trucks are often more fuel-efficient than larger models, which can result in significant cost savings for businesses that operate a fleet of trucks. This is particularly important given the current economic climate, where every penny counts.



The versatility of small dump trucks is another key advantage. They can be used for a variety of tasks, from hauling dirt and debris to transporting landscaping materials and construction equipment. This makes them a valuable asset for businesses that need a reliable vehicle for a range of jobs.



Small dump trucks are also cost-effective, with a lower initial purchase price and lower maintenance costs than larger trucks. This makes them an attractive option for small businesses and independent contractors who need a reliable vehicle but have limited budgets. Additionally, their smaller size can make them easier to park and maneuver in urban areas, further adding to their appeal. Finally, many small dump trucks are equipped with advanced safety features such as rearview cameras and automatic emergency braking systems, which can help prevent accidents and protect drivers and passengers.



Model UQ-5
Engine Model FAW - 4DW92-73
Engine Power 54KW/73HP
Transmission Model WANLIYANG 530
Transmission Gear 5 Forward Gear, 1Back Gear,Rear High Speed Controller
Drive Mode 4x2
Front Axle Model 1069
Rear Axle Model 1069
Tire Model 700x16 Line Tire,
Rear Double Tyre One Side,
No.of Bottom Spring Plate Front 10 PCS, Rear 10 PCS, Spare 6PCS
Dimension of Bottom Spring Plate Length 70mm, Width 100mm
Size of the Bucket:Length×width×height U type Bucket 2800mm*1600mm*550mm
Type of Bucket
Thickness of Bucket Steel Plate bottom 8mm side 6mm
Unloading Type Hydraulic Double Top Dump
Steering Type Hydraulic power steering
Braking Type Air Brake
Cabin Canopy with Glass and Rain Bush
Driving Position Left Hand Drive
Cooling sytem Standard Water Cooling System
Loading Capacity 6 Tons



U Type Bucket 73HP Mini Articulated Truck  5 Ton Red Tipper Truck  High Safety 0U Type Bucket 73HP Mini Articulated Truck  5 Ton Red Tipper Truck  High Safety 1U Type Bucket 73HP Mini Articulated Truck  5 Ton Red Tipper Truck  High Safety 2U Type Bucket 73HP Mini Articulated Truck  5 Ton Red Tipper Truck  High Safety 3U Type Bucket 73HP Mini Articulated Truck  5 Ton Red Tipper Truck  High Safety 4U Type Bucket 73HP Mini Articulated Truck  5 Ton Red Tipper Truck  High Safety 5
