Fuel Efficiency Underground Mining Truck 10 Ton Articulated Truck With Canopy Cabin

1
MOQ
Fuel Efficiency Underground Mining Truck 10 Ton Articulated Truck With Canopy Cabin
Features Gallery Product Description Request A Quote
Features
Specifications
Engine Model: YUNEI 4102 With Turbocharge
Engine Power: 70KW/95HP
Transmission Model: Wanliyang 545
Drive Mode: 4x2
Dimension Of Bottom Spring Plate: Length 70mm, Width 13mm
Loading Capacity: 10 Tons
Type: Underground Mining Dump Truck
Application: Mine
High Light:

Fuel Efficiency Underground Mining Truck

,

Canopy Cabin 10 Ton Tipper Truck

,

Fuel Efficiency 10 Ton Tipper Truck

Basic Infomation
Place of Origin: China
Brand Name: Beijun
Certification: CE,ISO
Model Number: UQ-10
Payment & Shipping Terms
Packaging Details: Customized packaging
Delivery Time: 9-12 days
Payment Terms: L/C, T/T
Supply Ability: 1000 Set/Sets per Month
Product Description

Product parameters of 10 Tons Mine Dump Trucks



The best power system is matched to give full play to the system performance, and there is a certain reserve of power and strong power.

Low fuel consumption, low emissions of pollutants, low noise, environmental protection and energy conservation.
The components have strong versatility, low operation and maintenance costs, and good economy.



Model UQ-10
Engine Model YUNEI 4102 with Turbocharge
Engine Power 70KW/95HP
Total Dimension 4800*1800*1600mm
Transmission Model Wanliyang 545
Transmission Gear 5 Forward Gear, 1Back Gear,Rear High Speed Controller
Drive Mode 4x2
Front Axle Model 1098
Rear Axle Model 1098
Tire Model 750-16 Line Tire,
Rear Double Tyre One Side,
No.of Bottom Spring Plate Front 10 PCS, Rear 10 PCS, Spare 6PCS
Dimension of Bottom Spring Plate Length 70mm, Width 10mm
Size of the Bucket:Length×width×height 3200mm*1800mm*600mm
Type of Bucket U type Bucket
Thickness of Bucket Steel Plate bottom 8mm side 6mm
Unloading Type Hydraulic Double Top Dump
Steering Type Hydraulic power steering
Braking Type Air Brake
Cabin Canopy
Driving Position Left Hand Drive
Cooling sytem Standard Water Cooling System
Loading Capacity 10 Tons



Fuel Efficiency Underground Mining Truck 10 Ton Articulated Truck With Canopy Cabin 0Fuel Efficiency Underground Mining Truck 10 Ton Articulated Truck With Canopy Cabin 1Fuel Efficiency Underground Mining Truck 10 Ton Articulated Truck With Canopy Cabin 2Fuel Efficiency Underground Mining Truck 10 Ton Articulated Truck With Canopy Cabin 3Fuel Efficiency Underground Mining Truck 10 Ton Articulated Truck With Canopy Cabin 4
