Compact Underground Dump Truck 35Tons Mining Transport Vehicles UQ-35Q

1
MOQ
USD 85000-90000 Set
Price
Compact  Underground Dump Truck 35Tons Mining Transport Vehicles UQ-35Q
Features Gallery Product Description Request A Quote
Features
Specifications
Engine Model: YC6MK375-T300
Engine Power: 276kW
Transmission Model: 10JS220
Drive Mode: 6x4
Size Of The Bucket:Length×width×height: 5400x2500x1350mm
Total Dimension: 7748x2500x2700
Front Axle Model: Styer Axle
Loading Capacity: 35 Tons
Braking Type: Air Brake
High Light:

Underground Dump Truck 35Tons

,

35Tons Mining Transport Vehicles

,

Compact Underground Dump Truck

Basic Infomation
Place of Origin: China
Brand Name: Beijun
Certification: CE,ISO
Model Number: UQ-35Q
Payment & Shipping Terms
Packaging Details: Customized packaging
Delivery Time: 7 days
Payment Terms: L/C, T/T
Supply Ability: 1000 Set/Sets per Month
Product Description

Product Features of 6*4 Underground Mining Dump Truck 35 Tons Dumper With High Quality



Beijun underground tunnel dump truck's features and design make it an excellent option for mining companies that need to operate in narrow underground spaces. Its compact structure, small turning radius, and strong obstacle-crossing capabilities ensure that it can safely and efficiently navigate through confined underground areas, while its powerful engine and strong bearing capacity enable it to handle heavy loads and steep inclines with ease. The truck's rugged construction enhances its durability and reliability in harsh underground environments, while its ergonomic design and comfortable cabin provide a comfortable working environment for operators, improving their productivity and well-being. Overall, the Beijun underground tunnel dump truck is a reliable and efficient solution for underground mining operations.



Product parameters of 6*4 Underground Mining Dump Truck 35 Tons Dumper With High Quality



Model UQ-35Q
Engine Model YC6MK375-T300
Engine Power 276kW
Total Dimension 7748x2500x2700
Transmission Model 10JS220
Transmission Gear 10 Forward Gear, 2Back Gear,Rear High Speed Controller
Drive Mode 6x4
Front Axle Model Styer Axle
Rear Axle Model Styer Axle
Tire Model 12.00R20
No.of Bottom Spring Plate Front 11 PCS, Rear 12 PCS
Dimension of Bottom Spring Plate Front 90*16
Rear 90*24
Size of the Bucket:Length×width×height 5400x2500x1350mm
Type of Bucket Right Angle Type
Thickness of Bucket Steel Plate bottom 10mm side 8mm
Unloading Type Hydraulic Double Top Dump
Steering Type Hydraulic power steering
Braking Type Air Brake
Cabin Closed Cabin
Driving Position Left Hand Drive
Cooling sytem Standard Water Cooling System
Loading Capacity 35 Tons
