Product Features of 25 Ton Underground Mining Dump Truck
The Beijun underground tunnel dump truck is an ideal vehicle for use in underground mining operations due to its compact design and specialized features. Its cab, suspension frame, vehicle frame, cargo compartment, and lifting mechanism have all been designed to provide maximum flexibility and maneuverability in narrow spaces. This makes it a highly versatile vehicle that can easily navigate underground roadways and ramps.
In addition to its maneuverability, the truck has also been designed with safety in mind. Its lamps and electrical components have been improved to ensure that they are able to function properly in the humid and poorly-lit underground environment. The truck's anti-slip tires and enhanced waterproof and moisture-proof performance also make it able to handle slippery road surfaces and other obstacles with ease.
The Beijun underground tunnel dump truck is also a strong performer, with powerful torque, excellent grade, and starting capabilities. Its high bearing capacity, which is 1.5 times that of an ordinary road vehicle, allows it to handle heavy loads and steep inclines with ease. Overall, the Beijun underground tunnel dump truck is a well-engineered vehicle that is capable of meeting the unique demands of underground mining operations.
Product parameters of 25 Ton Underground Mining Dump Truck
| Model | UQ-25 |
| Engine Model | Yuchai YC6L340-33 |
| Engine Power | 243KW |
| Total Dimension | 7900x2420x2720mm |
| Transmission Model | FASITE RT11509C |
| Transmission Gear | 10 Forward Gear, 2Back Gear,Rear High Speed Controller |
| Drive Mode | 6x4 |
| Front Axle Model | Styer Axle |
| Rear Axle Model | Styer Axle |
| Tire Model | 1100R20 Radial steel tire, Rear Double Tyre One Side, |
| No.of Bottom Spring Plate | Front 11 PCS, Rear 12 PCS |
| Dimension of Bottom Spring Plate | Front 90*16 Rear 90*24 |
| Size of the Bucket:Length×width×height | 5000x2300x1200mm |
| Type of Bucket | Right Angle Type |
| Thickness of Bucket Steel Plate | bottom 10mm side 8mm |
| Unloading Type | Hydraulic Double Top Dump |
| Steering Type | Hydraulic power steering |
| Braking Type | Air Brake |
| Cabin | Closed Cabin with A/C |
| Driving Position | Left Hand Drive |
| Cooling sytem | Standard Water Cooling System |
| Loading Capacity | 25 Tons |
