Styer Axle Model Underground 25 Ton Dumper Truck 6x4 Large Torque UQ-25

1
MOQ
Styer Axle Model Underground 25 Ton Dumper Truck 6x4  Large Torque UQ-25
Features Gallery Product Description Request A Quote
Features
Specifications
Engine Model: Yuchai YC6L340-33
Engine Power: 243KW
Transmission Model: FASITE RT11509C
Drive Mode: 6x4
Dimension Of Bottom Spring Plate: "Front 90*16 Rear 90*24
Cabin: Closed Cabin With A/C
Type Of Bucket: Right Angle Type
Loading Capacity: 25 Tons
Cooling Sytem: Standard Water Cooling System
High Light:

Styer Axle 25 Ton Dumper Truck

,

Styer Axle Dumper Truck 6x4

,

25 Ton Dumper Truck large torque

Basic Infomation
Place of Origin: China
Brand Name: Beijun
Certification: CE,ISO
Model Number: UQ-25
Payment & Shipping Terms
Packaging Details: Customized packaging
Delivery Time: 7 days
Payment Terms: L/C, T/T
Supply Ability: 1000 Set/Sets per Month
Product Description

Product Features of 25 Ton Underground Mining Dump Truck



The Beijun underground tunnel dump truck is a specialized vehicle designed for use in underground mining operations. Its compact structure and small turning radius make it highly maneuverable in tight spaces, while its specialized features like the cab, suspension frame, vehicle frame, cargo compartment, and lifting mechanism provide maximum flexibility.



Safety is a key consideration in the design of the Beijun truck, given the challenging conditions present in underground environments. To ensure driver safety, the truck has been equipped with improved lamps and electrical components, as well as anti-slip tires and enhanced waterproofing and moisture-proofing capabilities.



In terms of performance, the Beijun underground tunnel dump truck is a powerful vehicle. Its strong torque, excellent grade, and starting capabilities enable it to handle heavy loads and steep inclines with ease. The truck's high bearing capacity, which is 1.5 times that of a regular road vehicle, further adds to its capabilities.



Overall, the Beijun underground tunnel dump truck is a well-designed vehicle that is ideal for use in underground mining operations. Its combination of maneuverability, safety features, and strong performance make it a valuable asset for mining companies looking to boost their efficiency and productivity.



Product parameters of  25 Ton Underground Mining Dump Truck


Model UQ-25
Engine Model Yuchai YC6L340-33
Engine Power 243KW
Total Dimension 7900x2420x2720mm
Transmission Model FASITE RT11509C
Transmission Gear 10 Forward Gear, 2Back Gear,Rear High Speed Controller
Drive Mode 6x4
Front Axle Model Styer Axle
Rear Axle Model Styer Axle
Tire Model 1100R20 Radial steel tire,
Rear Double Tyre One Side,
No.of Bottom Spring Plate Front 11 PCS, Rear 12 PCS
Dimension of Bottom Spring Plate Front 90*16
Rear 90*24
Size of the Bucket:Length×width×height 5000x2300x1200mm
Type of Bucket Right Angle Type
Thickness of Bucket Steel Plate bottom 10mm side 8mm
Unloading Type Hydraulic Double Top Dump
Steering Type Hydraulic power steering
Braking Type Air Brake
Cabin Closed Cabin with A/C
Driving Position Left Hand Drive
Cooling sytem Standard Water Cooling System
Loading Capacity 25 Tons
