Versatility 5 Ton Red Dump Truck 4X2 Underground Mining Truck UQ-5

1
MOQ
Versatility 5 Ton  Red Dump Truck 4X2 Underground Mining Truck UQ-5
Features Gallery Product Description Request A Quote
Features
Specifications
Engine Model: FAW - 4DW92-73
Engine Power: 54KW/73HP
Transmission Model: WANLIYANG 530
Drive Mode: 4x2
Dimension Of Bottom Spring Plate: Length 70mm, Width 100mm
Loading Capacity: 5 Tons
Type Of Bucket: U Type Bucket
Thickness Of Bucket Steel Plate: Bottom 8mm Side 6mm
High Light:

versatility Red Dump Truck

,

versatility Underground Mining Truck

,

Red Dump Truck 4X2

Basic Infomation
Place of Origin: China
Brand Name: Beijun
Certification: CE,ISO
Model Number: UQ-5
Payment & Shipping Terms
Packaging Details: Customized packaging
Delivery Time: 7 days
Payment Terms: L/C, T/T
Supply Ability: 1000 Set/Sets per Month
Product Description

Product parameters of 5 Ton Mining Dump Truck



Small dump trucks offer excellent maneuverability, allowing them to operate in tight spaces and navigate narrow roads with ease. This makes them an ideal choice for construction projects or landscaping jobs where space is at a premium.



In addition to their maneuverability, small dump trucks are often more fuel-efficient than larger models, making them an attractive option for companies looking to reduce their fuel costs. This is particularly important for businesses that operate a fleet of dump trucks and want to keep their operating expenses under control.



The versatility of small dump trucks is another key advantage. They can be used for a wide range of tasks, from hauling dirt and debris to transporting landscaping materials and construction equipment. This makes them a valuable asset for contractors and businesses that need a reliable vehicle for a variety of jobs.



Small dump trucks are also a cost-effective option, with a lower initial purchase price and lower maintenance costs than larger models. This makes them a popular choice for small businesses and independent contractors who need a reliable vehicle but don't want to break the bank. Additionally, their smaller size can make them easier to park and maneuver in urban areas, further adding to their appeal.



Model UQ-5
Engine Model FAW - 4DW92-73
Engine Power 54KW/73HP
Transmission Model WANLIYANG 530
Transmission Gear 5 Forward Gear, 1Back Gear,Rear High Speed Controller
Drive Mode 4x2
Front Axle Model 1069
Rear Axle Model 1069
Tire Model 700x16 Line Tire,
Rear Double Tyre One Side,
No.of Bottom Spring Plate Front 10 PCS, Rear 10 PCS, Spare 6PCS
Dimension of Bottom Spring Plate Length 70mm, Width 100mm
Size of the Bucket:Length×width×height U type Bucket 2800mm*1600mm*550mm
Type of Bucket
Thickness of Bucket Steel Plate bottom 8mm side 6mm
Unloading Type Hydraulic Double Top Dump
Steering Type Hydraulic power steering
Braking Type Air Brake
Cabin Canopy with Glass and Rain Bush
Driving Position Left Hand Drive
Cooling sytem Standard Water Cooling System
Loading Capacity 6 Tons



Versatility 5 Ton  Red Dump Truck 4X2 Underground Mining Truck UQ-5 0Versatility 5 Ton  Red Dump Truck 4X2 Underground Mining Truck UQ-5 1Versatility 5 Ton  Red Dump Truck 4X2 Underground Mining Truck UQ-5 2Versatility 5 Ton  Red Dump Truck 4X2 Underground Mining Truck UQ-5 3Versatility 5 Ton  Red Dump Truck 4X2 Underground Mining Truck UQ-5 4
