12 Tone Mini Underground Dump Truck 4x2 Small Turning Radius

USD 1000-7000 Set
12 Tone Mini Underground Dump Truck 4x2 Small Turning Radius
Features Gallery Product Description Request A Quote
Engine Model: YUNEI 4102 With Turbocharge
Engine Power: 81KW/110HP
Transmission Model: Wanliyang 545
Drive Wheel: 4x2
Dimension Of Bottom Spring Plate: Length 70mm, Width 10mm
Color: Customer's Request
Capacity (load): 1 - 12t
Type: Dumping Truck
High Light:

12 Tone Underground Dump Truck


Underground Dump Truck Small Turning Radius


Small Turning Radius Dump Truck 4x2

Basic Infomation
Place of Origin: China
Brand Name: Beijun
Certification: CE,ISO
Model Number: UQ-12
Payment & Shipping Terms
Packaging Details: Customized packaging
Delivery Time: 7 days
Payment Terms: L/C, T/T
Supply Ability: 1000 Set/Sets per Month
Product Description

Product parameters of Mini Underground Mining Dump Truck with Loading Capacity 12 tons


The Beijun underground tunnel dump truck is specifically designed for excellent trafficability, featuring a compact structure and small turning radius that enable it to easily navigate narrow spaces inside the roadway ramp. This makes it a reliable and flexible option for mining companies operating in confined underground areas.


Safety is a top priority for the Beijun truck, which is equipped with improved lamps and electrical components, waterproofing and moisture-proofing capabilities, and dedicated anti-slip tires. These features enable the truck to overcome obstacles and maintain high safety standards, even in the challenging underground environment.


The Beijun underground tunnel dump truck boasts a powerful engine, with large torque, excellent grade, and starting performances, which enables it to easily handle heavy loads and steep inclines. This improves efficiency and productivity, allowing mining companies to optimize their operations and reduce costs.


The truck's scientific design and configuration, based on the mining vehicle design concept, ensures that it has a strong bearing capacity, 1.5 times that of an ordinary road vehicle. This makes it a reliable and cost-effective choice for transporting heavy loads in underground mining operations, improving overall efficiency and profitability. Furthermore, the truck's rugged construction, including its lifting mechanism, cargo compartment, suspension frame, and vehicle frame, enhance its durability and reliability in the harsh underground environment. Additionally, the truck's comfortable cabin and easy-to-use controls provide a pleasant and efficient working experience for operators, increasing their productivity and job satisfaction. Finally, the truck's advanced technology, including its telematics system and real-time monitoring capabilities, allows mining companies to track and optimize their operations and ensure maximum efficiency and safety.


Model UQ-12
Engine Model YUCHAI 4102 with Turbocharge
Engine Power 81KW/110HP
Total Dimension 5000*2000*1700mm
Transmission Model Wanliyang 545
Transmission Gear 5 Forward Gear, 1Back Gear,Rear High Speed Controller
Drive Mode 4x2
Front Axle Model 1098
Rear Axle Model 1098
Tire Model 825-16 Radial steel tire,
Rear Double Tyre One Side,
No.of Bottom Spring Plate Front 10 PCS, Rear 10 PCS, Spare 6PCS
Dimension of Bottom Spring Plate Length 70mm, Width 10mm
Size of the Bucket:Length×width×height 3400mm*2000mm*700mm
Type of Bucket U-type
Thickness of Bucket Steel Plate bottom 8mm side 6mm
Unloading Type Hydraulic Double Top Dump
Steering Type Hydraulic power steering
Braking Type Air Brake
Cabin Canopy
Driving Position Left Hand Drive
Cooling sytem Standard Water Cooling System
Loading Capacity 12 Tons

12 Tone Mini Underground Dump Truck 4x2 Small Turning Radius 012 Tone Mini Underground Dump Truck 4x2 Small Turning Radius 112 Tone Mini Underground Dump Truck 4x2 Small Turning Radius 212 Tone Mini Underground Dump Truck 4x2 Small Turning Radius 312 Tone Mini Underground Dump Truck 4x2 Small Turning Radius 4
